Right Angle Disc Sander Dynabrade 52656, 53869

test

Right Angle Disc Sander Dynabrade 52656, 53869

  • Use with 51151 Backing Pad (not included), 180 mm (7″) diameter, with mounting hardware. Accepts optional 180 mm (7″) diameter Abrasive Discs with 22 mm (7/8″) center hole.
  • Dynabrade’s 1.3 hp (970 W) Right Angle Sander offer countless grinding and material removal solutions to industries such as metal/stainless steel fabrication, composites, masonry, ironwork and general welding. Designed to the Dynabrade standard of excellence, these tools offer a wide array of features to increase efficiency and maximize operator comfort!Vibration Dampening Side Handle Specially designed to reduce vibration transfer to operator. Removable for left or right hand use. Rotational Exhaust System Rotates a full 360 degree to ensure that exhaust is directed away from operator.
  • Cast Aluminum Construction Tool housing and handle made of solid cast aluminum. Safety-Lock Throttle Lever Prevents accidental start-up of tool. Lever has no sharp edges or pinch-points.
  • Wick-Lube System for Longer Gear Life extends gear life with simple lubrication. All models include Gear Oil and Gear Oil Gun. Insulated Throttle Handle Reduces cold air transmission to operator’s hand. Handle position is adjustable, increasing comfort and efficiency.
  • Robust 1.3 hp Air Motor 1.3 hp (970 W) governor-controlled air motor delivers powerful, efficient performance. Convenient Spindle Lock Allows quick and easy change of grinding wheel or abrasive disc. Less downtime!

Industry:

Metal construction, Automotive supplier, Aeronautical engineering, Tool making, Medical technology, Locksmith, Foundry, Contract grinder

Scope:

Stainless steel, high-alloy and unalloyed steel, non-ferrous metals, cast steel, aluminum, titanium, plastics, glass, paper, for components such as turbine blades or die-cast and investment castings

Delivery time: Available at short notice

    Request a quote


    Your contact details





    Address



    These details enable us to recommend the most suitable system: (optional)










    Information about the machine used (optional)










    We need fields marked with * to process your request.

    Request a quote

    Technical specifications

    Model number5265653869
    Backing Pad Diameter Inch (mm)180 mm (7″)180 mm (7″)
    hp (W)1.3 (970)1.3 (970)
    Free Speed RPM60008500
    Tool Spindle ThreadM14 x 2 MaleM14 x 2 Male
    Exhaust TypeSideSide
    Max. Air Flow @ 90 PSIG: SCFM (L/Min.)40 (1,138)40 (1,138)
    Hose I.D. Size Inch (mm)3/8″ (10)3/8″ (10)
    Length Inch (mm)10″ (255)10″ (255)
    Height Inch (mm)3-9/16″ (90)3-9/16″ (90)
    Sound Level dB(A)7676
    Vibration Tool Peak Axis ISO8662 (m/sec²)1.321.32
    Item Weight2.04 kg2.04 kg

    Data sheets and spare parts

    Operating instructions and spare parts list Dynabrade compressed air angle grinder 52656, 53869 (PDF)
